Beskrivning
CONNECTIONS:
RJ45 x 2 Selectable as Switched, Redundant DANTETM or Independent Ethernet/DANTETM modes
BNC 75Ω Coaxial x 2: for MADI (AES10), AES3 or AES/EBU (requires Neutrik’s NADITBNC-F or -FX impedance-matching transformer)
Optical INPUT:
MADI
Optical OUTPUT:
MADI
LOUDSPEAKER OUTPUTS:
Phoenix / Euroblock
POWER-OUTPUT (per channel):
280W @ 4Ω | 140W @ 8Ω
BRIDGED POWER-OUTPUT:
Adjacent channel pairs can be bridged to output 500W @ 8Ω. Bridged channel pairs can also drive 750W | 4Ω loads – but 4Ω bridges must be limited to one pair per 8 x channel module (therefore up to 4 x bridged 4Ω pairs per 32 x channel amplifier). Bridged channel pairs can also deliver 70V RMS.
POWER INPUT:
90-264VAC @50/60Hz via IEC C13/CEE22 lockable connector. Individual amplifier channels can be deactivated via the software, to save PSU power.
LOAD MONITORING:
Each channel output is measured and fed to a 20kHz detector. By adding a pilot tone via either the internal generator or an external source, the connection and voice coil of your speakers can be monitored. Threshold and debounce time is adjustable per channel.
CONTROL:
AES67. Open standard for audio over IP or ethernet interoperability, developed by the Audio Engineering Society. It’s a layer 3 protocol suite designed to enable interoperability between audio networking systems such as RAVENNA & DANTE.
AES70. Web-based, platform-independent, remote control for straightforward usability. mDNS (Bonjour) to discover devices on your network. IP settings can be changed across IP subnet borders by the use of a simple propriety UDP implementation.
DSP:
FPGA based 32-bit fixed point. Each and every channel features:
5 x EQs (1 x High & 1 x Low-pass), Peak, Shelving, Allpass & Notch filters, High/Low-pass (6-48dB/ Oct, Bessel, Butterworth,
Linkwitz/Riley, Variable Q), Compressor/Limiter, Hard Clip Limiter and Volume. Sample Accurate Delay up to 1s (c330m).
IIR Filters:
32 x IIR Filters per channel.
FIR FILTER:
2048 x Tap Filters per Channel. ASCII file import.
Loudspeaker Presets:
Build read and write protected presets for specific speakers. Import, export and share them.
Integral test-tone generator:
Sine, white, pink and brown-noise.
Cooling:
Forced-cooling (front-to-back)
DIMENSIONS:
H 87.5mm (2RU) x W 482.6mm x D 398mm
